OneUp Components SPD Clip Pedals -
-
Light enough for cross country and durable enough for downhill. OneUp Clip Pedals are an ultra thin, super light pedal with a DH-size platform and a secure feel that you can fine tune. They're SPD compatible and available in 8 colours.
-
These are your new favourite pedals.
Ā
Product Specs
Ā
Weight:Ā 410g with pins (4 pins per side)
Thickness:Ā 14.4mm (body), 26.8mm (binding)
Size: 80mm x 90mm (W x L)
Stance width:Ā 57.5mm (centre of clip to outside of crank face)
Float: 5Ā° (12Ā° release angle)
Cleats:Ā SPDā¢ Compatible (includes 1mm cleat spacers for shoe fit tuning )
Bearing configuration:Ā Inboard igusĀ® Bushing and 3x outboard sealed cartridge bearings
Axle:Ā Chromoly Steel with Black ED coating
Pins: Hollow M5x8mm threaded pins (self-cleaning hex through hole)
Colours:Ā Black, Red, Green, Blue, Orange, Purple, Grey, Bronze
Ā
Ā
What's in the Box
Ā
Ā
2x Clip Pedals (1x Left, 1x Right)
4x Installed hollow threaded pins per side (16x pins total)
2x OneUp Cleats with included hardware
2x Cleat Spacers
1x Pedal Bearing Nut Tool
